グリーン・レッドテープは,柔軟なプリント回路板 (FPC) の狭いストリップを基板として使用し,表面に均等に分布し,非黄色化シリコンまたはPUポット層でコーティングされています.3M産業級の接着剤は迅速な取付けのために背面に適用されます。ロールで供給され,サイズにカットされ,線形アウトラインや間接照明などの専門的なアプリケーションに適しています.純純純純純純純純純純純純純純純純純純純な緑緑緑緑緑緑緑緑の緑緑緑緑緑緑緑緑緑緑緑緑緑緑緑緑緑緑緑緑緑緑緑緑緑
グリーン・レッドテープは,120-180 LEDs/メートルの密度,700-1100 lm/メートルの典型的な光フラックス,および120°のビーム角を使用して,均一でダークフリーの照明を使用し,小売およびディスプレイグレードの照明要件を満たしています.
光の波長は520〜535 nmの間に集中し,色色許容度は <3 SDCM and high color saturation. It is ideal for display lighting that aligns with the brand's primary color scheme, creating a clear green visual language.
Power ranges cover 6/9.6/12/14.4 W/meter. Combined with high-efficiency drivers, typical system power consumption for a 5-meter strip is less than 75W. It complies with ErP energy efficiency and RoHS environmental protection requirements.
Green Led Tape is available in DC12V/24V versions. The 24V version supports continuous LED strips up to 10 meters on a single end, with lower voltage drop. Its ≥2KV ESD protection design provides enhanced reliability.
Indoor version IP20; surface-coated/sleeved version IP65; extruded silicone fully encapsulated version IP67/IP68, suitable for long-term outdoor use. Operating temperature range -20°C to +50°C.
Available widths of 8/10/12 mm, with a minimum bend radius ≥30 mm. Cutting pitches of 25/50 mm are available, and the end features 2-pin/4-pin quick connectors for easy on-site splicing.
Dual mounting solution with 3M 300LSE adhesive and stainless steel clips on the back. Supports 0–10V, PWM, DALI, and DMX dimming control, compatible with mainstream control systems.
For shelf light troughs and door headlines, choose 24V, 120 LEDs/meter, 9.6W/meter, and SDCM<3 Green LED Tape to ensure uniform, fade-free strips. 50mm cuts easily fit display dimensions and enhance the visibility of green-themed displays.
Green LED Tape uses an IP20 indoor version with an 8mm width, concealed between the bar counter and soft packaging. CRI ≥ 90 (enhanced green color rendering) ensures a clearer view of the cup body and branding materials. A single 5m cable allows for neat routing and flicker-free photography.
A linear wall washer is built into the ceiling, equipped with 24V, 14.4W/m, and a 120° beam angle. It connects to a DALI system for scene-based dimming, boasting a continuous operation time of over 50,000 hours (L70) and low maintenance.
IP67 extruded silicone is recommended, resistant to UV and salt spray. It operates in temperatures of -20°C to +50°C and is stable in rain and fog. 10m long-distance wiring reduces power points and provides guidance for nighttime rides.
1200 lm/m high-brightness Green LED tape is used around the display stand, ensuring a uniform, grain-free light pattern. The dual-retention 3M adhesive backing and snap-on design prevents contact and detachment from frequent pedestrian traffic. It integrates with a 0–10V dimmer to create a ceremonial delivery experience.
Use 10mm wide, ultra-dense Green LED tape with 180 LEDs/meter to delicately outline product edges. PWM 1kHz dimming eliminates photographic streaks, making on-site photography more user-friendly. Quick connectors enable on-site layout changes in less than 10 minutes.
Use 9.6W/meter Green LED tape for overhead guides and shelf end guides, ensuring clear identification from a distance. Compatible with UL/CE certified power supplies, it's quick to replicate across multiple stores, and standardized material lists for each store facilitate procurement.
